First time soldering my own chip! 👏
It's also the first time I've used a stencil.
The chip is my Greyhound v1 (http://github.com/mole99/greyhound-ihp), designed for the IHP SG13 process family.
Read on for the full thread ⬇️
Remote
mole99
@mole99@fosstodon.org
mastodon 4.7.3Hi! I'm Leo, an open-source silicon advocate. This means that I'd like to advance chip design using open-source EDA tools and open-source PDKs. I am one of the maintainers of LibreLane and I regularly contribute to the three open-source PDKs (sky130, gf180mcu and ihp-sg13).
So how did I get there? Well, I wanted to understand computers at the deepest level, and transistors are pretty much the bottom of it all as far as I'm concerned :)
278 Followers
174 Following
19 Posts
Joined March 30, 2019
Leos Blog:
Replying to
The shuttle includes various RISC-V SoCs, a "3D" ray caster, a 100Mbps 4-port Ethernet switch and beacon, a dual Core BIO from #Baochip1x, three different #TinyTapeout chips, and much more!
There are also a number of designs that use the new community-created standard cell library, which is both faster and uses less power: a Linux-capable RISC-V SoC with MMU and FABulous FPGA.
Finally, there are new SRAM macros and inductors for validation and characterization, to be used in future runs.
A Tiny FABulous FPGA on Tiny Tapeout? It's more likely than you think!
Yesterday the TTIHP26a shuttle (https://app.tinytapeout.com/shuttles/ttihp26a) from #TinyTapeout has closed. In it, hundreds of incredible projects.
You can view the full shuttle and its designs here: https://app.tinytapeout.com/projects/3744
I had the opportunity to submit an FPGA, which I created using my FABulous LibreLane plugin. For this fabric, I developed a "tiny" tile library that better fits the constraints of Tiny Tapeout.
Greyhound is alive! 🐶
Last week, I posted about soldering my custom chips onto breakout boards. Now, I can finally say that Greyhound is working 🎉
If the video below doesn't work, you can also view it on Peertube: https://makertube.net/w/3rQ8a7WxTYcr1BQY9nCUat
I'm incredibly happy that Greyhound is no longer just theoretical, but that it can run examples on its FPGA in the real world 🤩
Greyhound repository: https://github.com/mole99/greyhound-ihp
And another chip submitted for tapeout - HeiChips 🎉
This one has been in the works for some time, but since the shuttle was canceled last fall, it was postponed to a later one.
It's an open-source chip featuring user projects created by participants of the HeiChips Summer School 2025 (https://heichips.github.io/). How cool is that?
The chip uses 9mm² of silicon on SG13CMOS and has been submitted to IHP's Low-Cost MPW shuttle (https://dk.ihp-microelectronics.com/OpenSourceRequest.php).
More below ⬇️
