amogus-scale features now possible at fafo
(behold, the sharpie lift-off process: scribble your substrate with a sharpie, deposit Al, dissolve sharpie with acetone)
Remote
FAFO Updates
@fafo@social.fa-fo.de
mastodon 4.6.5Follow us for updates about FAFO, the non-profit semiconductor and analytical chemistry lab in Munich.
Post by our members (see our following list).
1242 Followers
12 Following
22 Posts
Joined July 26, 2024
big succ doesn't want you to know this, but you can just put petg 3d prints in a vacuum chamber and blast them with aluminium
Did we just made a Schottky diode?
Al on n-doped Si. Random Fe contacts to Al and Si to measure. Positive lead to Si, negative to Al.
X = V (2V per division)
Y = I (100mA per 1V, so 5mA per division.)
(the I/V curve is a composite image of two waveforms)
Si has its protective oxide layer forcefully removed using abrasive methods (ie. sandpaper [!] - still working on being able to handle HF safely).
Not sure if it matters, but the Al is thermally evaporated aluminum foil from EDEKA.
fafo logistics: "poor decisions, delivered fast"
beans
vacuum pump mayoinnaise
Replying to
Time for a FAFO Special: a 3D printed ISO KF to toilet roll adapter... also known as a DIY oil mist filter. At least temporarily. We should probably invest in some real filters that aren't a possible fire hazard.
(toilet roll filter idea by @spirit532, 'engineered' at FAFO, soon coming to a Printables near you..?)
(yes, we take out the inner cardboard)
Replying to
On a more serious note: We're currently working on an interferometer for measuring the nanometer-scale displacement by the piezo stack actuators of our scanning tunneling microscope (STM).
To do this without budget, we started working on a 3d-printed system of optomechanics, all designed with @FreeCAD. It works surprisingly well! We'll publish the designs soon, including measurements of their stability performance.
You can read more about the project(s) here: https://wiki.fa-fo.de/projects:optics:start
bonzi buddy is helping
little guy's just vibing
the factory^Wlab must grow
(New room acquired! We're still just setting it up, but it should soon turn into a proper space to hack on lighter stuff and chill in between experiments.)
Replying to
Special thanks to visiting scientist @gigabecquerel who not only brought us some diff pump oil but also helped us get the instrument actually running.
Today at FAFO: hitting rocks (in this case pyrite) with a hammer and then putting it under a SEM.
Replying to
@xeno Yes, I checked already, Fe/Si/Fe seems ohmic, maybe with a _slight_ nonlinearity - but not nearly as pronounced as Fe/Al/Si/Fe above. But it's difficult to get a low resistance path to measure that well right now...
~q3k
Replying to
New plan: we're now delayed by 20-30 minutes.
The delay is subject to change. We apologize for the delay.
Thank you for trâwelling with the Deutsche Bahn.
Replying to
@StripeyYena Oh don't worry, we also have these two gathering dust, ie. waiting for utilities hookup and general love. We should exchange notes!
Left is a sputter system, right is a combined e-beam/thermal system.
(Maybe we should make a bringup vlog for them?)
OH: fafo? more like snafo
@16af93@wetdry.world @famfo@frogs.lgbt but then again, have you ever seen us in the same room at the same time?
