Migrated my little electronics shop from Tindie to Lectronz today. Took some effort to get all back-and-forth links between the shop and my website in sync again, but at least the import tool at Lectronz made copying the product pages from Tindie easy.
https://lectronz.com/stores/offerman
#Tindie @tindie@hackaday.social #Lectronz @lectronz@mastodon.social #electronics
Got me a whole range of 7-segment LED display elements: 0.8", 0.56", 0.39", 0.36", 0.28", and all sizes in 1/2/3/4-number units. Now let's take measurements and see what fits nicely in the little display window of my cockpit housing.
just uploaded for download:
KiCad footprint for 16+1-segment LED display elements, 0.8" height
https://offerman.industries/downloads/kicad/download/3-kicad/26-kicad-footprint-for-16-1-segment-led-display-elements-0-8-height
just uploaded for download:
KiCad footprint for 7+1-segment LED display elements, 0.8" height
https://offerman.industries/downloads/kicad/download/3-kicad/25-kicad-footprint-for-7-1-segment-led-display-elements-0-8-height
